Splinting for Stabilizing Traumatized Teeth - A Case Report

Dr Kumar Abhishek^1*,Dr Richa singh², Dr Shailesh Kumar chunnu³

1. Department of periodontology and oral implantology, Hazaribagh college of dental sciences and hospital.

2. Department of periodontology and oral implantology, Hazaribag college of dental  sciences and hospital . Hazaribag.

3. Department of pediatric and preventive dentistry. Kothiwal dental college.

*Correspondence to: Dr Kumar Abhishek, Department of periodontology and oral implantology, Hazaribagh college of dental sciences and hospital.

Copyright

© 2024 Dr Kumar Abhishek. This is an open access article distributed under the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

Received: 24 May 2024

Published: 01 June 2024

Abstract

Trauma to teeth is one of the most serious dental injuries, and it requires correct and timely management for the favorable prognosis. Splinting of teeth is considered best practice to maintain the repositioned tooth in the correct position, provide patient comfort and improve function. Amongst several methods, splinting with composite and wire is an economical, maintainable and flexible option for 20-year-old-female with two years follow up. Stabilizing traumatized mobile teeth. This case report shows splinting of teeth with composite and wire of traumatized teeth in a 20-year old female patient.

Keywords: Composite and wire; dental injuries; splinting.

Introduction

Dental trauma is a common problem we encounter in our day-to-day dental practice. A splint has been defined as ‘an apparatus used to support, protect or immobilize teeth that have been loosened, replanted, fractured or subjected to certain endodontic surgical procedures.1 Splinting has been recommended for repositioning the tooth/teeth to stabilize the tooth/teeth and to enhance healing outcomes for the pulp and/or the periodontal ligament.2 Amongst many methods of splinting of teeth, composite and wire splint is probably most common, economic and easily available.3The flexible splint has a wire diameter of not greater than 0.3–0.4 mm (up to 0.016” or 0.4 mm) and allows functional movement.1 International Association of Dental Traumatology (IADT) guidelines recommend splinting types that are flexible rather than rigid and employed for a shorter duration.4 According to B Kahler et al. 2016, the splint should allow periodontal ligament reattachment, stabilized teeth, maintenance of hygiene, preferably fulfill aesthetic appearance and provide patients comfort 5

Case Report

A 20-year-old female reported to the Department of Periodontology and Oral Implantology, Hazaribag college of dental sciences and hospital with a chief complaint of mobility of lower front teeth following fall injury. Medical history was non-contributory. She was conscious and well oriented with time, place and person during examination. Clinically, there was grade ii mobility in 31,41 with tenderness present. Radiographic examination revealed periodontal ligament widening irt 31,41. Written informed consent was taken after explaining about her condition, different treatment options, the nature of the procedure, the prognosis of teeth and the required follow up. Treatment began with non-surgical phase. Proper

extraoral asepsis with 2% povidone-iodine was followed by intraoral preprocedural 0.2% chlorhexidine rinses. After scaling and debridement of area, teeth were repositioned manually after explaining the complications related to it. The composite wire-splint was constructed using a ligature stainless steel round wire. The wire was cut to the desired time length and three strands of ligature wire were tightly held with one needle holder at one end and other end held with another needle holder which was moved clockwise multiple until desired twisted intertwined multistrand structure obtained and then placed on the lingual surfaces without bending, so as to provide neutrality.

Figure 1 a, Figure 1b

Figure 2

Lingual aspects of the teeth were spot etched using 37% phosphoric acid gel for 30 seconds (VISTA VIS- 502115 Best-Etch Dentsply), rinsed off with air-water spray for 10 seconds and then air-dried. A thin layer of bonding agent (Prime & Bond NT Dentsply) was applied on the etched surfaces as per the manufacturer’s instructions. The splint was secured with light curing resin composite (Spectrum Dentsply) with 30 seconds of photopolymerization (Figure 1a). Once the splinting with composite and wire was performed, the patient was counselled and an intraoral periapical radiograph was taken to evaluate the tooth repositioning . The splint was evaluated for its stability, mobility, premature contact and comfort to the patient. The patient was given antibiotics (Amoxicillin 500 mg for every eight hours a day for seven days and Metronidazole 400 mg for every eight hours a day for seven days) to prevent infection as chance of spread of infection due to higher vascularization. The analgesics (Ibuprofen 400 mg every eight hours a day for three days) was given to reduce pain and decrease inflammation for improving healing with 0.2% chlorhexidine gluconate rinse every 12 hours for 14 days as an antiplaque mouth rinse. Postoperative written instructions for the consumption of a soft diet, maintenance of regular oral hygiene, avoidance of direct trauma by mastication, oral habits and immature contact were given. The patient was recalled after one week and examined for the stability of the splint. Splint was

placed for four weeks with weekly evaluation. At end of four weeks, splint was removed (Figure 1 b) with diamond bur. After one year of continuous three months follow up, the patient referred in the Endodontics for further treatment. At two years of follow up, color, contour, position of gingiva was excellent, well maintained alveolar bone height (Figure 2) & the patient was completely satisfied with result obtained.

Table 1

Discussion

The IADT guidelines recommend a flexible splint for all injury classifications except for alveolar fracture where no recommendation is given either to use flexible or rigid (Table 1).6 In this case report, splinting time was four weeks similar to ideal requirement of splint for intrusive luxation according to

International Association of Dental Traumatology (IADT) guidelines. The teeth were repositioned manually for faster restoration of discrepancy in occlusion and chewing habits despite being chance of damaging vital periodontal tissue than slow self or orthodontic eruption. All five teeth required endodontic treatment may be either due to previous traumatic injury or manual manipulation. The wire used in our case were round stainless-steel ligature wire, used in orthodontics and were of diameter 0.33 mm which is considered flexible splint.. Slight modification in wire was done in our case by using three strands twisted intertwined multistrand ligature wire to provide slight rigidity because all four incisors are mobile.6 Splinting with this method shows favorable and excellent patient perspective results. In the context of our country like INDIA, the composite and multistrand ligature wire splints may also act as alternative treatment approach as it is an easy, economical, provides optimal result and seems one of the best options.

Conflict of Interest: None.

References

1. American Association of Endodontists. Glossary of Endodontic Terms. 10th ed. Chicago: 2020.44.

2. Oikarinen KS. Splinting of traumatized teeth. In: Andreasen JO, Andreasen FM, Andersson L.

Textbook and Color Atlas of Traumatic Injuries to the Teeth. 4th ed. Oxford, UK: Wiley-Blackwell; 2007:842-51.

3. Andersson L, Lindskog S, Blomlof L, Hedstrom K-G, Hammarstrom L. Effect of masticatory stimulation on dentoalveolar ankylosis after experimental tooth replantation. Endod Dent Traumatol. 1985; 1:13–6.

4. International Dental Association of Dental Traumatology. Available at: URL: https://www.iadt- dentaltrauma.org/1-9%20%20iadt%20 guidelines%20combined%20-%20lr%20-%2011-5- 2013.pdf

5. Khaler B, Hu J-Y, Marriot-Smith CS, Heithersay G. Splinting of teeth following trauma: a review and a new splinting recommendation. Aust Dent J. 2016; 61(1): 59–73.

6. DiAngelis A J, Andreasen J O, Ebeleseder K A, Kenny D J, Trope M, Sigurdsson A et. al.

International Association of Dental Traumatology guidelines for the management of traumatic dental injuries: 1. Fractures and luxations of permanent teeth, 2012; 28:2-12.
